APX-103
Description
DIN 3113, Press Panel (Anti Skid)
Chrome Vanadium Steel
Hardened and Tempered
Each Head set at 15° angle.
Available in Matt Finish / Satin Finish.
| Size MM | Size SAE | Weight in Gms |
|---|---|---|
| 6 | 1/4” | 0.018 |
| 7 | 0.022 | |
| 8 | 5/16” | 0.026 |
| 9 | 0.030 | |
| 10 | 3/8" | 0.042 |
| 11 | 7/16” | 0.052 |
| 12 | 0.060 | |
| 13 | 1/2” | 0.072 |
| 14 | 9/16” | 0.086 |
| 15 | 0.092 | |
| 16 | 5/8” | 0.109 |
| 17 | 11/16” | 0.132 |
| 18 | 0.152 | |
| 19 | 3/4” | 0.160 |
| 20 | 0.182 | |
| 21 | 13/16” | 0.192 |
| 22 | 7/8” | 0.210 |
| 23 | 0.250 | |
| 24 | 15/16” | 0.260 |
| 25 | 1" | 0.300 |
| 26 | 0.320 | |
| 27 | 1-1/16” | 0.390 |
| 28 | 1-1/8” | 0.435 |
| 29 | 0.460 | |
| 30 | 0.460 | |
| 32 | 1-1/4” | 0.560 |
| Metric Sizes Sets | |||
|---|---|---|---|
| No. of Pcs | Set | Sizes mm | Weight in Gms |
| 6 Pcs | 8-17 | 8, 10, 12, 13, 14, 17 | |
| 8 Pcs | 8-19 | 8, 9, 10, 11, 13, 14, 17, 19 | |
| 8 Pcs | 8-19 | 8, 10, 12, 13, 14, 15, 17, 19 | |
| 12 Pcs | 6-22 | 6, 7, 8, 9, 10, 11, 12, 13, 14, 17, 19, 22 | |
| 12 Pcs | 6-24 | 6, 8, 9, 10, 12, 13, 14, 15, 17, 19, 22, 24 | |
| 14 Pcs | 8-32 | 8, 9, 10, 11, 12, 13, 14, 17, 19, 22, 24, 27, 30, 32 | |
| 25 Pcs | 6-32 | 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 30, 32 | |
